Features
High mechanical strength, impact resistance
Protection performance, water and oil proof
Long life with spring structure design
Characteristics
|
Operation speed
|
0.01mm-50m/sec
|
|
Operating frequency
|
Mechanical: 120 operations/min. Electrical: 30 operations/min.
|
|
Contact resistance
|
100MΩ min. ( at 500VDC )
|
|
Insulation resistance
|
25MΩ max. (initial)
|
|
Vibration
|
10-55Hz,1.5mm double amplitude
|
|
Shock
|
Mechanical durable: 1, 000m/Sec2 (about 100G’S)
Malfunction: 300m/Sec2 (about 30G’S)
|
|
Ambient temperature
|
-10℃ to +70℃
|
|
Humidity
|
95% RH max.
|
|
IP Rate
|
IP64
|
|
Life
|
Mechanical: 20,000,000 operations
Electrical: 500,000 operations
|
